01 · The diagnostic split
When an oven won't heat in a Southern California home, our techs at Same Day Appliance Repair trace it to a handful of patterns: a weak gas igniter ($200 to $340), bake element burnout ($200 to $360), or a drifted temperature sensor ($200 to $340). We run the igniter-current or element-resistance test before replacing anything, because visual inspection alone misses partial failures. $89 residential diagnostic, waived with repair. BHGS #A49573, EPA 608 Universal certified (#1346255700410), BBB Accredited.
An oven that won't heat usually comes down to a failed bake or broil element (electric, year 7 to 10), a weak gas igniter (about 50% of gas calls, current drops below the 3.5A threshold so the gas valve safety stays closed), or a drifted temperature sensor reporting wrong values to the control board. Our techs at Same Day Appliance Repair test the element or igniter first because visual inspection plus a quick resistance or current check usually tells us the answer before we open the control panel — and most shops skip the test and replace based on age, which wastes parts.
The diagnostic logic forks at gas-vs-electric. Same symptom (oven won't reach temp, won't get warm at all, or heats then quits), three or four very different root causes per fuel type. Most expensive mistake: replacing the gas valve when the actual problem is a weak igniter that costs a third as much.
Our techs run the same test sequence on every not-heating call: igniter current measurement on gas units, element resistance test on electric units, RTD sensor resistance check, control-board diagnostic-mode entry. The order matters, and skipping steps leads to swap-and-pray repairs that cost more in the long run.
$89 residential diagnostic, waived with repair. BHGS #A49573, EPA 608 Universal certified (#1346255700410), BBB Accredited. Phones answered 24/7.
02 · Gas oven not heating
Most common gas oven failure. The glow-bar igniter must hit roughly 3.5A current draw to trigger the gas valve safety to open. Below that threshold, the igniter glows visibly but the gas valve never opens, no flame, no heat. Visible glow is misleading: customers see the orange glow and assume the igniter is fine, while the current has actually dropped below threshold from age. Replacement $200 to $340.
Even with a strong igniter, the gas valve safety can seize closed mechanically. Diagnostic: confirm igniter current is at or above spec, then test gas valve operation directly. If the igniter is good and gas isn't flowing, the valve is the culprit. $440 to $680.
Less common but happens. Gas line pressure dropped (regulator issue, supply problem) below burner spec. Burner won't sustain a flame even when ignited. We test pressure at the manifold during a live call. Resolution often requires gas-supply contractor coordination, we identify and refer.
03 · Electric oven not heating
Visible burn-through on the lower coil, usually at one end where the element flexes most under thermal cycling. Resistance test confirms: healthy bake element reads 19 to 30 ohms; broken element reads infinite resistance (open circuit). Replacement $200 to $360 with labor.
Same failure mode as bake element. Broil sees less use so it lasts longer, year 10 to 14 typical. Same resistance test, same replacement cost band.
Convection ovens have a third heating element behind the rear wall, paired with a fan. Bake and broil might work fine while convection is dead. Diagnostic isolates the failed element. Convection element $260 to $440.
Sometimes the element is fine but the relay on the control board that switches it on has failed. We diagnose the relay before condemning the element. Control board replacement $440 to $720 mid-market, $680 to $1,100 pro-style (Wolf, Viking, Thermador).
04 · Both gas and electric, common failures
RTD sensor drift, control board failure, and door switch issues hit gas and electric ovens equally — and they're the second-line suspects after the element or igniter. We test them in order on every not-heating call because the sensor and door switch are inexpensive fixes and the control board is the most expensive one to swap on guess.
05 · Recent jobs
Composite examples; model numbers, ages, and prices are accurate to typical scope.
Owner reported oven "trying to heat", pulled in two parts on Amazon (gas valve and igniter) before calling us. We tested the igniter first: current measured 2.8A versus 3.5A spec. Replaced igniter, gas valve was unnecessary (we returned it for the customer). Total: $89 plus $230 igniter plus 45 minutes = $290. Customer kept the unneeded gas valve as a spare, no upsell.
Bake element visible burn-through near right end. Replaced bake element, ran 350°F preheat test, verified setpoint reach in 12 minutes. Total: $89 plus $310 element plus 30 minutes = $440.
Igniter tested fine at 3.6A, gas valve operating, sensor resistance in spec. Control board not enabling heat command. Replaced control board, recalibrated oven temp, verified bake and broil function. Total: $89 plus $580 board plus 1.5 hours = $720.
Cooktop working, oven not heating. RTD sensor resistance reading 1,250 ohms (should be ~1,080). Replaced sensor, confirmed temp recovery to setpoint. Total: $89 plus $235 sensor plus 45 minutes = $310.
Customer assumed the induction generator board failed and was killing the whole unit. Diagnostic told a different story: induction generator board (which drives the cooktop coils) was fine, all four cooktop zones induction-tested with magnetic test cookware. The oven side, on a separate resistive bake element, had its own independent failure: bake element open-circuit. Replaced bake element only. Generator board untouched, $890 part the customer assumed was needed. The induction generator board drives the cooktop, not the oven. On induction ranges, oven not heating is the resistive bake element, not the generator board. Total: $89 plus $260 element plus 1 hour = $360. Saved customer $890 by testing both sides separately.
06 · Honest opinion
The most expensive avoidable mistake on gas oven not-heating calls is replacing the gas valve when the actual problem is a weak igniter. Igniter $200 to $340, valve $440 to $680. Online forums full of customers who were sold a valve replacement when an igniter would have fixed it. Test the igniter current first. Always.
On electric ovens: visual inspection of the bake element catches obvious breaks, misses partial failures. Resistance test takes two minutes and confirms the diagnosis. Don't replace based on appearance alone.
On induction ranges: the generator board is for the cooktop only. When the oven won't heat on a Bosch HEI, Samsung NZ slide-in induction, or GE Profile induction, the bake element is the suspect, not the generator board. We see customers assume the generator failure killed everything, when actually two independent components failed (or only the resistive oven side did).
07 · Pricing
| Service | Cost |
|---|---|
| Diagnostic visit | $89, waived with repair |
| Gas igniter replacement (glow-bar) | $200 to $340 |
| Gas valve safety replacement | $440 to $680 |
| Bake element (electric) | $200 to $360 |
| Broil element (electric) | $200 to $360 |
| Convection element (electric) | $260 to $440 |
| Temperature sensor (RTD) | $200 to $340 |
| Door switch | $200 to $340 |
| Control board (mid-market) | $440 to $720 |
| Control board (pro-style Wolf/Viking/Thermador) | $680 to $1,100 |
| Multi-component repair | $700 to $1,200 |
| Warranty | 90 days parts and labor |
Residential $89 diagnostic, applied toward repair. No emergency surcharge.
08 · Why us
Sister sub-services: temperature off, door issues, self-clean problems. Parent: oven repair. Related: range repair, wall oven repair. Credentials: BHGS license, EPA 608.
09 · FAQ
Cooktop burners and oven heat are independent systems on most ranges, so a working cooktop doesn't tell you anything about the oven side. On a gas range, the cooktop has its own ignition system separate from the oven's glow-bar igniter; oven not heating usually means a weak igniter (about 50% of calls) or a stuck gas valve safety. On an electric or induction range, the cooktop and oven use completely different heat sources — induction coils for the cooktop, resistive bake/broil elements for the oven. A failed bake element doesn't affect the cooktop at all. We diagnose the oven side independently at $89 residential, applied toward repair.
An oven that heats but doesn't reach setpoint usually points to a drifted temperature sensor (RTD probe reads higher than actual, so the control board cycles heat off early), a weakening bake element (partial failure — heating unevenly across its length), or a weak gas igniter that opens the valve briefly then drops below the 3.5A safety threshold. Resistance test on the sensor (should read about 1,080 ohms at room temp) and current draw on the igniter give us the answer in 5 minutes. Don't replace the element on appearance alone — partial-failure elements often look fine.
Click means the spark electrode is firing, but the burner isn't igniting. On gas ovens with a glow-bar igniter (most common), 'click' is the wrong symptom. Glow-bar ovens don't click, they glow visibly. If yours clicks instead, you may have a hot-surface ignition pilot system that's lost gas pressure, or the gas valve safety isn't opening. We diagnose with a gas pressure gauge first.
Yes. Visual inspection catches obvious breaks but misses partial-failure cases where the element heats unevenly across its length. We test resistance with a multimeter. A healthy bake element reads 19 to 30 ohms. Open circuit means break (visible or invisible). Off-spec resistance means partial failure. Replacement either way, the test confirms which side of the line you're on.
Two common causes. (1) Temperature sensor (RTD probe) drifted, sensor reports oven already at setpoint when it isn't, control board cycles heat off. We test sensor resistance at room temp (should read about 1,080 ohms). (2) Cooling fan failure on convection ovens, control board protective shutoff when ambient cabinet temp rises too high. Both are diagnosable in one visit.
Same diagnostic logic, different parts cost. A Wolf DF range oven that won't heat goes through the same igniter-current and sensor-resistance tests we'd run on a GE Profile. Difference: the Wolf igniter or sensor part costs more (premium OEM, sometimes 2 to 3x). But the test sequence prevents wasted parts, on either tier.
Not safely without an inline clamp meter on the live circuit. Igniter glow color is a partial visual proxy: bright orange means strong current, dim red or yellow-orange means weak. If your glow looks dim, that's a strong indicator. Confirm with us, $89 diagnostic includes the current measurement.
No — on an induction range the oven side is a separate resistive bake element, not the induction generator board that drives the cooktop. Our techs at Same Day Appliance Repair test the bake element independently (a healthy element reads 19 to 30 ohms) and the RTD sensor before touching the generator board, which saves customers the cost of a part the oven failure never needed. Bake element replacement runs $200 to $360. $89 residential diagnostic, waived with repair.
Only after the cheaper suspects are ruled out — the control board is the most expensive swap and the easiest to condemn by guess. Our techs at Same Day Appliance Repair confirm the igniter, element, RTD sensor, and door switch are all good before quoting a board, which runs $440 to $720 mid-market or $680 to $1,100 pro-style (Wolf, Viking, Thermador). Testing in that order keeps a $440 board from being swapped when a $200 sensor was the real fault. $89 residential diagnostic, waived with repair.
90 days parts and labor on every repair. If the same component fails inside 90 days we replace it free. BHGS #A49573, EPA 608 Universal certified (#1346255700410), BBB Accredited Business.
$89 residential diagnostic, waived with repair. Same-day across LA, OC, Ventura. 24/7 phones, no emergency surcharge. BHGS #A49573, EPA 608 Universal certified (#1346255700410).
